VPN Configuration Guide for Sensitive Cloud

A Virtual Private Network (VPN) allows secure access to environments that are isolated from the public internet. At CERIT-SC, we use WireGuard VPN technology. To begin using the VPN, you must first request access and receive the necessary configuration details.

Please refer to the next section for instructions on how to obtain access.

Obtaining VPN Access

To gain access to secure resources via our VPN, contact our support team at:
trusted(at)e-infra.cz

Connecting to the VPN with WireGuard

The following guide explains how to configure your WireGuard VPN client using the configuration files provided upon registration.

Make sure your configuration includes an IPv6 address derived from your IPv4 address.
The IPv4 format is: 10.18.x.y/32
The corresponding IPv6 format is: 2001:718:801:390:10:18:x:y/128

The IPv6 address uses : as a separator. A format like 2001:718:801:390:10.18.x.y might be accepted by the system, but it will not work. It must be exactly: 2001:718:801:390:10:18:x:y

The AllowedIPs field in your configuration should be set to:

AllowedIPs = 10.16.48.0/25, 10.16.62.0/23, 147.251.33.144/28, 147.251.33.160/30, 2001:718:801:42bf:8:4::/96, 2001:718:801:42d8:8:4::/96, 2001:718:801:42d9:8:4::/96
⚠️

Never share your PrivateKey. It must remain confidential. The rest of the configuration is not considered sensitive.

⚠️

Each WireGuard configuration file is intended for use on a single device only. If you need to connect from multiple devices, please request separate configurations for each one.

  1. Install WireGuard
    Download the WireGuard installer for Windows here and follow the installation instructions.

  2. Create Configuration File

    • Create a configuration file named sensitive-vpn.conf. Save this file securely within your personal directory, for example:
      C:\Users\<username>\Documents\sensitive-vpn.conf
    • Example configuration file contents (replace placeholders with values provided by our support team):
      [Interface]
      PrivateKey = DESKTOP_CLIENT_PRIVATE_KEY
      Address = 10.0.0.2/24

      [Peer]
      PublicKey = SERVER_PUBLIC_KEY
      Endpoint = SERVER_IP_ADDRESS:PORT
      AllowedIPs = 0.0.0.0/0
  3. Launch WireGuard Application

  4. Import VPN Configuration

    • From the WireGuard interface, click “Import tunnel(s) from file”.
    • Select the previously created sensitive-vpn.conf.

    wg1

  5. Connect to VPN

    • Select the imported VPN tunnel.
    • Click “Activate”.

    wg2

  6. Disconnecting

    • To deactivate the VPN, select the active tunnel and click “Deactivate”.

    wg3

  1. Install WireGuard

    • Follow official WireGuard installation instructions for your Linux distribution found here.
  2. Configure VPN

    • Create the file /etc/wireguard/wg0.conf with the configuration details provided by our support team.
    • Example configuration file:
      [Interface]
      PrivateKey = DESKTOP_CLIENT_PRIVATE_KEY
      Address = 10.0.0.2/24

      [Peer]
      PublicKey = SERVER_PUBLIC_KEY
      Endpoint = SERVER_IP_ADDRESS:PORT
      AllowedIPs = 0.0.0.0/0
  3. Start VPN

    • Open your terminal and execute:
      sudo wg-quick up wg0
  4. Check VPN Status
    To verify if the VPN tunnel is active, run:

    wg-quick show
  5. Disconnect VPN
    To deactivate the VPN tunnel, execute:

    wg-quick down wg0

Install WireGuard

  1. Download and install the WireGuard VPN Client from the Mac App Store.

Create VPN Configuration

  • Securely create the file sensitive-vpn.conf in your home directory (e.g., /Users/<username>/sensitive-vpn.conf) using the configuration details provided by our support team.
  • Example configuration:
    [Interface]
    PrivateKey = DESKTOP_CLIENT_PRIVATE_KEY
    Address = 10.0.0.2/24

    [Peer]
    PublicKey = SERVER_PUBLIC_KEY
    Endpoint = SERVER_IP_ADDRESS:PORT
    AllowedIPs = 0.0.0.0/0

Launch WireGuard Application

  • Open the WireGuard application from your Applications folder.

Import VPN Configuration File

  • In the WireGuard interface, select “Import tunnel(s) from file”.
  • Choose your previously created sensitive-vpn.conf file.

Activate VPN Connection

  • Select the imported configuration and click “Activate”.

Disconnect VPN

  • To disconnect, select the active VPN tunnel and click “Deactivate”.
